ROCNA

Ancre Vulcan 4-40 KG

Ancre Vulcan 4-40 KG

Prix habituel €335.95 EUR
Prix habituel €344.00 EUR Prix promotionnel €335.95 EUR
En vente À commander
Taxes incluses. Frais d'expédition calculés à l'étape de paiement.
Poids

Ancre Vulcan 4-40 KG

The VULCAN anchor is an evolution of the Rocna anchor. It has the same good properties (high holding force, as well as fast and reliable dig), but is more compact and has a favorable design for anchor holders at the prow and sunbathing platforms.
Breaking from the Rocna design, the Vulcan features an unique combination of shank and fluke geometry - including an innovative "roll-palm" (A) which self-rights the anchor on the seabed without the use of a roll-bar.
This is assisted by the "V-bulb" (B) which extends fluke ballast downward to gain maximum leverage and efficiency.
The Concave fluke (C) is similar in design to the Rocna, directly equating to more holding power and security.
The omission of a roll-bar along with a carefully designed shank profile (D) ensures a snug fit on bowsprits, prods and platforms.
In addition to the use of high tensile steel, shank strength is optimized by a unique "I + V profile" shank design (E), granting improved resistance to bending courtesy of a computer optimized I-beam geometry. This visually elegant innovation also improves setting performance, with the lower "V" edge (F) cutting into the seabed and minimizing resistance to a deep and secure burial.
There are fixing eyes for safety and rescue lines, as well as for a tandem anchor.
weight
kg
Blade area A
mm
B
mm
C
mm
E
mm
F
mm
S
mm
width
mm
4,0 kg 430 cm² 472 142 145 46 119 67 258
6,0 kg 560 cm² 541 163 167 53 136 77 296
9,0 kg 730 cm² 619 186 191 61 156 88 339
12,0 kg 890 cm² 681 205 210 67 172 97 373
15,0 kg 1030 cm² 734 221 226 72 185 104 402
20,0 kg 1250 cm² 808 243 249 79 204 115 442
25,0 kg 1450 cm² 870 262 268 85 220 124 476
33,0 kg 1740 cm² 955 287 294 93 241 136 522
40,0 kg 1980 cm² 1018 306 313 100 257 145 557




To choose the right size for your Rocna anchor pick out the correct vessel length on the left side on the chart. As second step search for the weight of your yacht. If the correct size is not clear at all please choose the next bigger one. Please also consider the territory where to want to use the anchor. On Multihull yachts please always choose the next bigger size.
  RV004 RV006 RV009 RV012 RV015 RV020 RV025 RV033 RV040 RV055
4 m <= 2 t
5 m <= 1 t <= 5 t
6 m <= 0,5 t <= 3,5 t <= 7 t
7 m <= 0,5 t <= 2 t <= 6 t <= 9 t
8 m   <= 1 t <= 5 t <= 8 t <= 12 t
9 m   <= 0,5 t <= 4 t <= 7 t <= 10 t <= 16 t
10 m     <= 3 t <= 6 t <= 8,5 t <= 14 t <= 22 t
11 m       <= 5 t <= 7 t <= 12 t <= 20 t
12 m       <= 4 t <= 6 t <= 10 t <= 18 t <= 30 t
14 m         <= 4 t <= 6 t <= 13 t <= 23 t <= 40 t
16 m           <= 3 t <= 9 t <= 18 t <= 32 t <= 60 t
18 m             <= 5 t <= 14 t <= 25 t <= 50 t
20 m               <= 10 t <= 18 t <= 40 t
22 m               <= 6 t <= 12 t <= 33 t
24 m                 <= 7 t <= 25 t
26 m                   <= 18 t
weight 4 kg
9 lbs
6 kg
13 lbs
9 kg
20 lbs
12 kg
27 lbs
15 kg
33 lbs
20 kg
44 lbs
25 kg
55 lbs
33 kg
73 lbs
40 kg
88 lbs
55 kg
121 lbs
